1. Introduction
Last week I did some work on the blog’s design, and I was a bit under the water, so I ended up forfeiting working on this blog post. Today I will start by doing a quick recap on how to get the lab deployed by using my GitHub files. It assumes that you have the Proxmox automated install .iso per Part 1. Then I will proceed to explain the CLI procedures for Corosync and Ceph. This part is way shorter and much more straightforward than what we’ve been doing before. I was aiming to get you to experience the process of scripting and figuring out what to do. Now we’re more practical. I don’t know if at any point I will script this. It’s possible. Maybe partially. You have a freedom to make mistakes and redeploy the whole lab in 3 minutes, use it.
2. Recap: Setting up the Lab
First, create the directory to receive the project:
mkdir -p ~/Projects
Then pull my GitHub repo:
cd ~/Projects
git clone https://github.com/tomlutkus/virtual-proxmox-lab
Next, make sure that you have the proper ACLs in your /var/lib/libvirt directory (Arch in my case, adjust to the package manager of your distro), so that we don’t need to be operating as root:
# Install the ACL package
sudo pacman -S acl
# Apply rwx permissions for your user to all existing files/dirs recursively
sudo setfacl -R -m u:$(whoami):rwx,m::rwx /var/lib/libvirt/
# Set default ACL - new files/dirs created inside inherit these permission
sudo setfacl -R -d -m u:$(whoami):rwx,m::rwx /var/lib/libvirt/
Make sure that your user is configured to connect to qemu:///system:
echo 'export LIBVIRT_DEFAULT_URI="qemu:///system"' >> ~/.bashrc
source ~/.bashrc
You must have the .iso files already. the full steps to create them are in part 1, this is just a short recap of what you need to get going with the scripts.
Now, deploy the lab:
cd ~/Projects/virtual-proxmox-lab/host/scripts
chmod +x deploy_lab.sh
./deploy_lab.sh
Watch the install run:
for N in pve-0{1..3}; do virt-viewer -w -r "${N}" & done
When the VMs power off, start them again and wait for them to give you the login prompt:
for N in pve-0{1..3}; do virsh start "${N}"; done
3. Corosync HA
This is where we wanted to get with today’s post. You now understand how to do an automated deployment of a Proxmox Virtual Cluster, and you have the ability to deploy and dismantle it at will, precisely in the same way. There are a lot of tutorials covering the next steps through the GUI, and I find that boring at this point. We should want to live in the CLI: everything is slow and so much clicking around the GUI. It’s more prone to mistakes. I will grant it: it’s great for getting started and understanding how it works.
3.1 Checking that the Nodes Talk
The first thing is to test that the nodes talk to each other. I will go the lazy path and test from just pve-01 and assume that everything is working, because it probably will, at this point:
ping -c 2 10.0.253.1
ping -c 2 10.0.253.2
ping -c 2 10.0.253.3
3.2 Creating the Corosync Cluster
We will be calling it lab-cluster, but name it however you like. We will let the nodes reference each other via the wan interface on the subnet 192.168.122.0/24, but in production you’d switch that to a management internal interface.
- Run the following command on
pve-01to initialize the cluster:
pvecm create lab-cluster --link0 10.0.253.1
- Then check if it’s up with
pvecm statusfor a similar output as bellow:
root@pve-01:~# pvecm status
Cluster information
-------------------
Name: lab-cluster
Config Version: 1
Transport: knet
Secure auth: on
Quorum information
------------------
Date: Sun Feb 15 17:55:29 2026
Quorum provider: corosync_votequorum
Nodes: 1
Node ID: 0x00000001
Ring ID: 1.5
Quorate: Yes
Votequorum information
----------------------
Expected votes: 1
Highest expected: 1
Total votes: 1
Quorum: 1
Flags: Quorate
Membership information
----------------------
Nodeid Votes Name
0x00000001 1 10.0.253.1 (local)
- SSH into
pve-02run the following, replyingyesto the prompt
pvecm add 192.168.122.1 --link0 10.0.253.2
- SSH into
pve-03run the following, replyingyesto the prompt
pvecm add 192.168.122.1 --link0 10.0.253.3
- Back into
pve-01run check the cluster withpvecm statusandcorosync-cfgtool -s:
Cluster information
-------------------
Name: lab-cluster
Config Version: 3
Transport: knet
Secure auth: on
Quorum information
------------------
Date: Sun Feb 15 17:57:42 2026
Quorum provider: corosync_votequorum
Nodes: 3
Node ID: 0x00000001
Ring ID: 1.d
Quorate: Yes
Votequorum information
----------------------
Expected votes: 3
Highest expected: 3
Total votes: 3
Quorum: 2
Flags: Quorate
Membership information
----------------------
Nodeid Votes Name
0x00000001 1 10.0.253.1 (local)
0x00000002 1 10.0.253.2
0x00000003 1 10.0.253.3
root@pve-01:~# corosync-cfgtool -s
Local node ID 1, transport knet
LINK ID 0 udp
addr = 10.0.253.1
status:
nodeid: 1: localhost
nodeid: 2: connected
nodeid: 3: connected
If your output is similar to mine, your Corosync is now fully configured.
4. Ceph
I mentioned before “fully redundant”. What I mean by that is not that each node is capable of running entirely alone, but that the cluster will handle one node loss. If 2 nodes are lost, the data protection is fully redundant, but it will block all I/O to protect data integrity, until the lost node(s) are back, then Ceph resumes and re-syncs automatically. This is the default size 3, min_size 2 configuration.
4.1 Install Ceph
In each of the nodes pve-01, pve-02 and pve-03, run the following command to install Ceph:
pveceph install --repository no-subscription
Answer yes to any prompt asking to about continuing.
Then proceed on node pve-01 run this to initialize Ceph:
pveceph init --network 10.0.254.0/24
4.2 Add MONs and MGRs
In each of the nodes pve-01, pve-02 and pve-03 proceed to add a MON and MGR on each:
pveceph mon create
pveceph mgr create
4.3 Create OSDs and Pool
Now let’s give shape to the whole thing. Create the OSDs out of the physical disks. First, check with lsblk:
root@pve-01:~# lsblk
NAME MAJ:MIN RM SIZE RO TYPE MOUNTPOINTS
sda 8:0 0 32G 0 disk
├─sda1 8:1 0 1007K 0 part
├─sda2 8:2 0 512M 0 part
└─sda3 8:3 0 31.5G 0 part
├─pve-swap 252:2 0 3.9G 0 lvm [SWAP]
├─pve-root 252:3 0 13.8G 0 lvm /
├─pve-data_tmeta 252:4 0 1G 0 lvm
│ └─pve-data 252:6 0 11.8G 0 lvm
└─pve-data_tdata 252:5 0 11.8G 0 lvm
└─pve-data 252:6 0 11.8G 0 lvm
sdb 8:16 0 150G 0 disk
sdc 8:32 0 150G 0 disk
sr0 11:0 1 1024M 0 rom
In my case, the drives /dev/sdb and /dev/sdc are the ones with 150GB that we set aside for Ceph. Make sure that yours are too in each node, otherwise adapt. Run on each node:
pveceph osd create /dev/sdb
pveceph osd create /dev/sdc
Now create the pool:
pveceph pool create ceph-pool --pg_autoscale_mode on
Then add it as a Proxmox storage backend:
pvesm add rbd ceph-pool --pool ceph-pool --content images,rootdir
4.4 Validate
Let’s make sure everything is healthy:
root@pve-01:~# ceph -s
cluster:
id: 193abaf8-c5a6-432b-b4ea-d86fb2587672
health: HEALTH_OK
services:
mon: 3 daemons, quorum pve-01,pve-02,pve-03 (age 4m)
mgr: pve-01(active, since 4m), standbys: pve-02, pve-03
osd: 6 osds: 6 up (since 2m), 6 in (since 2m)
data:
pools: 2 pools, 129 pgs
objects: 2 objects, 577 KiB
usage: 161 MiB used, 900 GiB / 900 GiB avail
pgs: 129 active+clean
All 3 MONs in quorum, 1 active MGR with 2 standbys, 6 OSDs up and in (2 per node), all PGs active+clean. You can also verify the OSD distribution:
root@pve-01:~# ceph osd tree
ID CLASS WEIGHT TYPE NAME STATUS REWEIGHT PRI-AFF
-1 0.87900 root default
-3 0.29300 host pve-01
0 hdd 0.14650 osd.0 up 1.00000 1.00000
1 hdd 0.14650 osd.1 up 1.00000 1.00000
-5 0.29300 host pve-02
2 hdd 0.14650 osd.2 up 1.00000 1.00000
3 hdd 0.14650 osd.3 up 1.00000 1.00000
-7 0.29300 host pve-03
4 hdd 0.14650 osd.4 up 1.00000 1.00000
5 hdd 0.14650 osd.5 up 1.00000 1.00000
Finally, confirm the replication settings:
ceph osd pool get ceph-pool size
ceph osd pool get ceph-pool min_size
You should see size: 3 and min_size: 2. Every object is replicated across all 3 nodes. Lose 1 node and the cluster keeps running. Lose 2 and I/O blocks to protect the data, but nothing is lost: bring the node(s) back and Ceph re-syncs automatically.
5. Conclusion
That’s it. Corosync was 3 commands. Ceph was a handful more. The cluster is fully redundant: data is triply replicated across nodes with automatic failover for monitors and managers. What took us several blog posts to automate and deploy took minutes to cluster.
If you want to practice it, you can leverage the destroy_lab.sh script, redeploy and master the commands.
In Part 5 we’ll deploy the Proxmox Backup Server and tie it into the cluster. See you then.
